14
PRECAUTIONS
WARRANTY &
ENVIRONMENT
PACKAGE
CONTENTS
DESCRIPTION &
FEATURES
INSTALL &
CONNECT
PANEL
FUNCTIONS
TECHNICAL
DATA
START-UP
OPERATION
Available
Applications
WebGUI
First Steps
Login WebGUI Info
Applications
Tips & Tricks
8.1.2 PULSO-6
PULSO-6
PI
Processor
Quad-Core ARM, up to 1.8GHz
SCREEN/DISPLAY
Size
5.5"
Resolution
720 x 1280 pixels
Contrast Ratio
1000:1
Brightness
400 cdm2
Scale
9:16
Display
5.5'' IPS Active area 62.08(W)x110.40(H)mm
Backlight
LED
Touch-panel
5 points capactive touch panel
MONITORING AND CONTROL
Buttons
Reboot and Factory Reset micro buttons
CONNECTIVITY
Ethernet
1 RJ-45 connector, cable: Cat-5e or better
10 /100Mb, 1GB Auto X-Over
Supports PoE
Serial port
RS-232, Euroblock connector
Programing and control
Embedded application. Compatible with Ecler products
ENM, EPX, VIDA, HALO, HUB.
ELECTRICAL
Power supply
DC 12V 2A & PoE
PoE
Class 0 802.3af Poe PD compliant
Max power consumption
7W
PHYSICAL
Type
Control touch panel
Format
Standard EU single-gang compatible
Installation options
In-wall and desktop (with optional accessory) mount
Operating temperature
Min: -10°C ; 14°F
Max: 60°C ; 140°F
Operating humidity
≤75%
Storage temperature
Min: -20°C ;-4°F
Max: 70°C ; 158°F
Storage humidity
≤75%
Included accessories
Security screw
Optional accessories
Pulso Desktop Mount (under development)
Dimensions (WxHxD)
82.5 x 146 x 37 mm / 3.25 x 5.75 x 1.46 in.
Weight
0.19 Kg / 0.42 lb
Shipping dimensions (WxHxD)
180 x 63 x 105 mm / 7.09 x 2.48 x 4.13 in.
Shipping weight
0.33 Kg / 0.73 lb
