16
Supply
Mains
90-264VCA 47-63Hz
Power consumption
45VA
Miscellaneous
Management Connectivity
Ethernet Base-Tx 10/100Mb Auto X-Over CAT5 up to 100m
Remote Bus
Over twisted pairs; up to 1km (see specific specs.)
GPI
8, from 0 to 10VDC or TTL level
Aux. Power Supply for Remotes & GPI
+12VDC, 1.2A. max. (short circuit protected)
Time and date retention (battery)
100 hours approx. (ambient temperature dependant)
RTC accuracy
±1 minute / month
Software
EclerNet Manager
From v3.03r4 version
9.2. MIMO1212SG
DSP
DSP
2x 32/64bit
Sampling Rate
48kHz
Latency IN to OUT
<3.2ms
Converters
Resolution
24bit AKM
Dynamic Range
AD:110dB, DA: 115dB
Analogue
12 Input/Output
Terminal block (Symmetrical)
Analogue Input headroom
+27dBV = +30dBu
Max. output level
+18dBV = +21dBu
Input sensitivity @ 0dBV out
From -50dBV to +10dBV in 0.5dB step
Input Impedance
Balanced, >4kΩ
Phantom power
+42VDC, 5mA max. software switched
Frequency response (-3dB)
5Hz to 24kHz
Flatness
better than ±0.1dB
THD+Noise @ 1kHz, 0dBV input (line)
<0.004%
THD+Noise @ 1kHz, -40dBV input
(mic.)
<0.008%
Output Noise floor FFT (20Hz - 20kHz)
better than 115dB
Interchannel crosstalk (20Hz - 20kHz)
better than 90dB (100dB typ.)
Channel Leakage (20Hz - 20kHz)
better than 100dB (115dB typ.)
CMRR 20Hz- 20kHz
65dB typ.
Processing
Input Level (x12)
Range: from Off to 0 dB
Mute: Yes
Signal Polarity reverse: Yes
Metering: VU + clip pre & post fader
