14
TECHNICAL CHARACTERISTICS
9.1. MIMO88SG
DSP
DSP
2x 32/64bit
Sampling Rate
48kHz
Latency IN to OUT
<2.9ms
Converters
Resolution
24bit AKM
Dynamic Range
AD:110dB, DA: 115dB
Analogue
x8 Input/Output
Terminal block (Symmetrical)
Analogue Input headroom
+27dBV = +30dBu
Max. output level
+18dBV = +21dBu
Input sensitivity @ 0dBV out
From -50dBV to +10dBV
in 0.5dB step
Input Impedance
Balanced, >4kΩ
Phantom power
+42VDC, 5mA max software switched
Frequency response (-3dB)
5Hz to 24kHz
Flatness
better than ±0.1dB
THD+Noise @ 1kHz, 0dBV input (line)
<0.004%
THD+Noise @ 1kHz, -40dBV input
(mic.)
<0.008%
Output Noise floor FFT (20Hz - 20kHz)
better than 115dB
Interchannel crosstalk (20Hz - 20kHz)
better than 90dB (100dB typ.)
Channel Leakage (20Hz - 20kHz)
better than 100dB (115dB typ.)
CMRR 20Hz- 20kHz
65dB typ.
Processing
Input Level (x8)
Range: from Off to 0 dB
Mute: Yes
Signal Polarity reverse: Yes
Metering: VU+clip pre & post fader
Output Level (x8)
Range: from Off to 0 dB
Mute: Yes
Solo: Yes
Signal Polarity reverse: Yes
Metering: VU+clip pre & post fader
Output Gain
Range: from 0 to +6 dB
Input Delay (x8)
from 0 to 1000 ms
Units: sec/ms/m/cm
Output Delay (x8)
from 0 to 1000 ms
Units: sec/ms/m/cm.
