17
Supply
Mains
90-264VCA 47-63Hz
Power consumption
45VA
Miscellaneous
Management Connectivity
Ethernet Base-Tx 10/100Mb Auto X-Over CAT5 up to
100m.
Expansion LINK BUS (16x16 ch.)
Proprietary over CAT5, Xover cable up to 100m.
Remote Bus
2, over twisted pairs; up to 1km (see specific specs.)
GPI
8, from 0 to 10VDC or TTL level
GPO
8, 3 poles isolated relay; 1A, 48VDC max.
Aux. Power Supply for Remotes & GPI
+12VDC, 1.2A. max. (short circuit protected)
Time and date retention (battery)
1 month aprox. (ambient temperature dependant)
RTC accuracy
±1 minute /year
SOFTWARE
EclerNet Software
Realtime full GUI of all functions and controls
thru Ethernet with interactive graphical display
Grouping mode channels or devices
Grouping of other groups
Automated report generation
Up to 256 devices on same net
Autodiscovery devices feature
Routing capability through NAT gateways
Real time metering at input/output (DSP)
Device “Finder” feature
Save & Recall setup and preset functions
Firmware update capability thru Ethernet
Password protection (device & project with two user
levels)
Default Network configuration:
IP: 192.168.0.100
Mask: 255.255.255.0
Gate: 192.168.0.1
UDP Port: 2210
Operating System
Windows® 10; W8.1; W8; W7; Vista (SP1); XP Prof.
(SP3); W2000 Prof. (SP4)
Minimum EclerNet System Requirements
Pentium IV ® 1GHz
512MB RAM
40MB HDD free space
800x600 pixels & 16bits color display
10/100/1G Ethernet Network card
