8. TECHNICAL DATA
8.1 Technical Specifications
8.1.1 IC6i
IC6i
SYSTEM
Effective Freq. Range
1
75Hz-20kHz (-10dB)
Coverage angle
2
163° conical
Power handling
40W RMS / 160W Peak
Sensitivity
3
90dB (1W/1m)
Maximum SPL
4
106dB continuous / 112dB peak
Power options
100V: 2.5 / 5 / 7.5 / 15W
70V: 1.25 / 2.5 / 3.75 / 7.5W
Recommended amplifier power
80 W RMS
TRANSDUCERS
Ways
2-ways full range
Low frequency driver
6.5" Woofer
High frecuency driver
1" Tweeter
Nominal impedance
8Ω
PHYSICAL
Connection type
Clip-Type input terminals
Installation options
In-ceiling / In-wall
Enclosure material
ABS plastic
Grille material
Iron
Grille fixing system
Magnets
Mounting system
3 rotating tabs
Operating temperature
Min: -20°C ; -4°F
Max: 70°C ; 158°F
Operating humidity
<85% HR
Storage temperature
Min: -20°C ; -4°F
Max: 70°C ; 158°F
Storage humidity
<90% HR
External diameter
213 mm / 8.39 in.
Internal diameter
205 mm / 8.07 in.
Recommended cut out diameter
180 mm / 7.09 in.
Required depth
>73 mm / >2.87 in.
Included accessories
Cutting template
Optional Accessories
Ecler IC-TB6
Finished colour
White (RAL 9003) / Black (RAL 9005)
Dimensions (WxHxD)
213 x 213 x 72 mm. / 8.39 x 8.39 x 2.83 in.
Weight
1.6 Kg / 3.53 lb
Pieces per box
2
Shipping dimensions (WxHxD)
265x260x255 mm. / 10.43x10.24x10.04 in.
Shipping weight
4 kg / 8.82 lb
1
below the sound pressure level at specified sensitivity
2
6dB below the sound pressure level than that at the direction of maximum level, Max. angle between 1 kHz and 4 kHz.
3
Measured on-axis, far field and referenced to 1 meter by inverse square law. Average from 100 Hz to 10 kHz.
4
Calculated from sensitivity and power handling specifications, exclusive of power compression
