8.3.8 EMS Modbus TCP Service
This section contains the configuration related to the EMS Modbus TCP/IP service, see Figure 50.
The Green Motion Building EV chargers can be seamlessly integrated into the Eaton Building Energy Management Software
(BEMS) to enable an end-to-end solution. EV chargers communicate with BEMS using the Modbus TCP/IP communication
protocol.
Steps to configure the EV charger to work with Eaton BEMS solution:
Step 1. Go to “EMS Modbus TCP service.”
Step 2. Check the “Enabled” checkbox. A set of new configuration options will appear.
Step 3. Confirm the pop-up message.
Step 4. Enter the parameters of the EMS installation:
•
The IP address on which an EMS is accessible as a client. This IP address will be authorized.
•
Enter Modbus TCP Port parameters.
Step 5. Click Apply at the bottom of the configuration page.
Figure 51. Configuration Page – EMS Modbus TCP Service
Description
Enabled Enable the service.
Port Port used for the TCP connection.
By default: 502
Failsafe timeout Failsafe delay after EMS disconnection.
By default: 30s
Failsafe max current Charger max current when failsafe timeout has elapsed after EMS disconnection.
By default: 6A
IP-based access control Authorize selected IPs to connect.
Authorized IP list Only available if access control is enabled.
IP addresses of the clients allowed to connect.
List IP addresses separated with a comma.
Example:
192.168.1.1, 192.168.1.3
Table 29. Modbus TCP/IP configuration
Refer to Eaton secure configuration guidelines for installing the product securely. You can download the
guidelines from the product page at www.eaton.com/greenmotion.
76
GREEN MOTION BUILDING INSTALLATION MANUAL MN191028EN April 2024 www.eaton.com
