1.1 Field of applications
This installation manual is intended for professional and qualified personnel. It describes how to securely install the
Green Motion Building AC EV charger.
Table 1. Overview of the Green Motion Building EV charger
1
It is not possible to install the unit in a 3-phase IT earthing system.
Power input AC EV charger
Input voltage
1 x 230 V (50 Hz) – 1 phase
3 x 400 V (50 Hz) – 3 phase
Input current
1 x 16 A (3.7 kW) – 1 phase
1 x 32 A (7.4 kW) – 1 phase
3 x 16 A (11 kW) – 3 phase
3 x 32 A (22 kW) – 3 phase
Earthing system compatibility TN, TT, IT (1-phase)
1
Power output
Output power 3.7 kW to 22 kW
Output type Type 2 cable (Mode 3) or socket (T2 or T2S)
Type of cables Straight
Simultaneous charging 1
Environmental
Operating temperature -25 °C to +45 °C
Altitude Up to 2000 m
Installation Wall-mounted; indoor or outdoor
Humidity < 95 % relative humidity
Mechanical
Mounting method
Wall-mounted
Floor-mounted column (optional)
Dimensions (W x H x D) in mm 285.5 x 264 x 116
Weight (without cables) 3 kg
Cable length 5 meters
Standards
Conformity IEC 61851-1
Degree of protection IP54
Earth leakage detection Built-in 6 mA DC RDC-DD protection according to IEC 62955
Impact strength IK08
1.2 Symbols used in this manual
Hazardous behaviors that could cause serious injuries. Hazardous behaviors that could cause death.
Imminent danger of causing serious injuries or death.
Behaviors that could cause minor injuries to people or minor damages to property.
1.2.1 Related icons
Risk of electric shock that can be fatal. Avoid touching internal or external parts normally live while the
system is powered on.
7GREEN MOTION BUILDING INSTALLATION MANUAL MN191028EN April 2024 www.eaton.com
