4 /9
SERVICE
No.
Name
Function Description
1
PWR LED
The green LED will be on when the unit is powered on.
2
LINK LED
The green LED will be on when the Transmitter and Receiver
are connected successfully.
3
SELECT button
Press the button to select USB HOST 1/2 circularly.
4
HOST 1
USB-B host port, connected to a PC or host.
5
DEVICE 1/2
USB-A device ports, connected to USB devices such as U disk
or hard disk. Output power is up to 5V/1A.
6
USB LED
USB signal pass-through indicator.
▪ On: USB 3.0 signal is detected.
▪ Blinking: USB 2.0 signal is detected.
▪ Off: USB signal is not detected.
7
HOST LED 1/2
When HOST 1/2 is selected as the input channel, the
corresponding LED will be on.
8
HOST 2
USB-C host port, connected to a PC or host.
9
HDBT-USB3
Connects to the HDBT-USB3 port on Receiver with CAT6a cable.
10
DC 24V
DC 24V/3.75A power input port.
11
FSYNC
FSYNC port, the level pass through from Transmitter to Receiver,
to synchronize the external devices. Default level range is 0~5V.
12
RS-232
3-pin phoenix connector, connected to a PC or control system
for RS-232 command pass-through.
13
SERVICE
USB-C port, used for firmware update.
