2 /9
3. Package Contents
① 1× USB 3.2 Gen 1 Wall-Plate Extender (Transmitter)
② 1× USB 3.2 Gen 1 Box Extender (Receiver)
③ 1× 24V/3.75A Power Supply
④ 1× 2pin-3.5mm Phoenix Connector (Male)
⑤ 2× 4pin-3.5mm Phoenix Connector (Male)
⑥ 2× Mounting Ear
⑦ 4× Machine Screw (KM3*4)
⑧ 2× Machine Screw (6#-32*3⁄4)
⑨ 1× Top Panel
⑩ 1× User Manual
4. Specifications
Technical
USB Protocol
USB 3.2 Gen 1
Transmission Rate
Up to 5Gbps
Transmission Distance
100m/328ft via CAT6a (F/FTP) cable
1.5m/4.9ft via USB cable
ESD Protection
IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
Connections
Transmitter
Input:
1× HOST 1 [USB Type C, 24-pin female]
1× HOST 2 [USB Type B, 9-pin female]
Output: 2× USB-A DEVICE [USB Type A, 9-pin female]
1× HDBT-USB3 [RJ45 connector, 24V PoC]
Control: 1× RS-232 [3pin-3.5mm phoenix connector]
1× FSYNC [1pin-3.5mm phoenix connector]
1× SERVICE [USB Type C, firmware update port]
Receiver
Input:
1× HDBT-USB3 [RJ45 connector, 24V PoC]
Output: 3× USB-A DEVICE [USB Type A, 9-pin female]
1× USB-C DEVICE [USB Type C, 24-pin female]
Control: 1× RS-232 [3pin-3.5mm phoenix connector]
1× FSYNC [1pin-3.5mm phoenix connector]
1× SERVICE [USB Type C, firmware update port]
