4. Specifications
Technical
USB Protocol
USB 3.2 Gen 1
Transmission Rate
Up to 5Gbps
Transmission Distance
100m/328ft via CAT6a (F/FTP) cable
1.5m/4.9ft via USB cable
ESD Protection
IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
Connections
Transmitter
Input: 1× HOST [USB Type C, 24-pin female]
Output: 1× USB-C DEVICE [USB Type C, 24-pin female]
2× USB-A DEVICE [USB Type A, 9-pin female]
1× HDBT-USB3 [RJ45 connector, 24V PoC]
Control: 1× RS-232 [3pin-3.5mm phoenix connector]
1× FSYNC [1pin-3.5mm phoenix connector]
1× SERVICE [USB Type C, firmware update port]
Receiver
Input:
1× HDBT-USB3 [RJ45 connector, 24V PoC]
Output: 2× USB-A DEVICE [USB Type A, 9-pin female]
2× USB-C DEVICE [USB Type C, 24-pin female]
Control: 1× RS-232 [3pin-3.5mm phoenix connector]
1× FSYNC [1pin-3.5mm phoenix connector]
1× SERVICE [USB Type C, firmware update port]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
TX / RX: 100mm [W] × 85mm [D] × 25.5mm [H]
Weight
TX: 265g; RX: 275g
Power Supply
Input: AC 100~240V 50/60Hz
Output: DC 24V/3.75A
Power Consumption
TX: 23W (Max); RX: 35W (Max);
TX+RX: 68W (Max, including line loss)
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Operating Humidity
20%~80% relative humidity, non-condensing
Storage Humidity
10%~90% relative humidity, non-condensing
