4. Specifications
Technical
HDMI Compliance
HDMI 2.0b
HDCP Compliance
HDCP 2.2 / 1.x
Video Bandwidth
594MHz / 18Gbps
Video Resolution
Input: 480i ~1080p50/60Hz, 4Kx2K@24/30Hz, 4K2K@60Hz
Loop Out: 480i ~1080p50/60Hz, 4Kx2K@24/30Hz, 4K2K@60Hz
Color Depth
8-bit, 10-bit, 12-bit (1080p@60Hz)
8-bit, 10-bit, 12-bit (4K2K@60Hz YCbCr 4:2:2 / 4:2:0)
8-bit (4K2K@60Hz YUV 4:4:4)
Color Space
RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0
HDR
HDR10, HDR10+, HLG, Dolby Vision
HDMI Audio Formats
LPCM, Dolby Digital/Plus/EX, DTS, DTS-EX, DTS-96/24, DTS
High Res, DTS-HD Master Audio
Coaxial Audio Formats
LPCM 2.0, LPCM 5.1, Dolby Digital 2/5.1CH
Analog Audio Formats
PCM 2.0CH
Extended Distance
115ft/35m at 4K2K@60Hz (600M Bandwidth)
164ft/50m at 4K2K@30Hz (300M Bandwidth)
197ft/60m at 1080p@60Hz (148.5M Bandwidth)
ESD Protection
Human body model±8kV (Air-gap discharge) &
±4kV (Contact discharge)
Connection
Input
1 × HDMI IN [Type A, 19-pin female]
Output
1 × HDMI LOOP OUT [Type A, 19-pin female]
2 × CAT OUTPUT [RJ45, 8-pin female]
1 × COAX AUDIO OUT [RCA]
1 × L/R AUDIO OUT [3.5mm Stereo Mini-jack]
Control
1 × SERVICE [Micro USB, Update port]
1 × IR OUT [3.5mm Stereo Mini-jack]
