5.3 LCD Display Navigation
The buttons on the the front panel are used for LCD display navigation, including
INPUT(1~4), OUTPUT(1~4), MATRIX, MULTIVIEWER, VIDEOWALL, MENU, ENTER,
UP, DOWN
.
Menu items are as follows:
Level 1
Level 2
Level 3
Level 4
OUTPUT
RESO
OUT1 / OUT2 / OUT3 / OUT4
4K×2K60W,
4K×2K50W,
4K×2K60,
4K×2K50,
4K×2K30,
1080P60,
1080P50,
1080i60,
1080i50,
WUXGA60_RB,
1360×768@60,
1280×800@60,
720P60,
720P50,
XGA60,
AUTO
CSC
OUT1 / OUT2 / OUT3 / OUT4
RGB 444
YUV 444
YUV 422
YUV 420
STREAM
OUT1 / OUT2 / OUT3 / OUT4
ENABLE
DISABLE
H MIRROR
OUT1 / OUT2 / OUT3 / OUT4
ENABLE
DISABLE
V MIRROR
OUT1 / OUT2 / OUT3 / OUT4
ENABLE
DISABLE
MV
MODE
SINGLE / PIP / DUAL /
TRIPLE-1 / TRIPLE-2 /
TRIPLE-3 / QUAD-1 /
QUAD-2 / QUAD-3 /
USER-1 / USER-2 / USER-3
ASPECT
FULL / 16:9
PIP POSITION
UPPER LEFT
LOWER LEFT
UPPER RIGHT
LOWER RIGHT
PIP SIZE
SMALL / MIDDLE /
LARGE
