2 / 38
4. Specifications
Technical
HDMI Compliance
HDMI 2.0
HDCP Compliance
HDCP 2.2
Video Bandwidth
594MHz/18Gbps
Video Resolution
480i ~1080P@50/60Hz, 4K2K@24/30Hz, 4K2K@60Hz
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth
8/10/12-bit
Audio Formats
LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-
96/24, DTS High Res, DTS-HD Master Audio
IR Level
12Vp-p
IR Frequency
Wideband 20K-60KHz
ESD Protection
IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
Connection
Input ports
4 × HDMI INPUT [Type A, 19-pin female]
4 × L/R AUDIO INPUT [3.81mm, 3pin Phoenix Connector]
Output ports
4 × HDMI OUTPUT [Type A, 19-pin female]
4 × OPTICAL AUDIO OUT [S/PDIF]
4 × L/R AUDIO OUT [3.81mm, 5pin Phoenix Connector]
Control ports
1 × TCP/IP [RJ45]
1 × RS-232 [D-Sub 9]
1 × IR EXT [3.5mm, Stereo Mini-jack]
4 × IR INPUT [3.5mm, Stereo Mini-jack]
4 × IR OUTPUT [3.5mm, Stereo Mini-jack]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
440mm [W] × 203mm [D] × 44.5mm [H]
Weight
2.55kg
Power Supply
Input: AC 100-240V 50/60Hz, Output: DC 12V/2.5A
(US/EU standard, CE/FCC/UL certified)
Power Consumption
25W (Max)
Operating
Temperature
32 - 104°F / 0 - 40°C
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no-condensing)
Video Resolution
4K60
4K30
1080P60
HDMI Cable Length
(HDMI IN / OUT)
5m/16ft
10m/32ft
15m/50ft
The use of “Premium High Speed HDMI” cable is highly recommended.
