6 / 21
Power on the Matrix or set it to standby mode.
Output 1/2/3/4
1/2/3/4
Select the desired input source IN 1/2/3/4 for the
OUT 1/2/3/4 port output, the corresponding green
LED on the front panel will be on.
SD
Switch downscale or bypass mode for the OUT
1/2/3/4 port output.
Select the last or next the desired input source
to OUT 1/2/3/4 port output, the corresponding
green LED on the front panel will be on.
6. IR Remote
7. Web GUI Operation Guide
The Matrix comes with built-in Web interfaces to provide a way to control or
configure various Settings. There are seven pages, each of which is detailed
in the following sections.
1. Status – Display information about the firmware and IP setting.
2. Video – Switch the desired input source to output and set the preset.
3. Input – Display information about the input signal and EDID setting.
4. Output – Display information about the output signal and scaler option.
5. CEC – Perform CEC management.
6. Network – Basic network settings management and Web login settings.
7. System – Panel lock, beep, serial baud rate setting and firmware update.
Note: All the above seven pages can be accessed in Admin mode.
Meanwhile, only the Status and Video pages are accessible in User mode.
To access the Web interface, please enter the IP address of the Matrix into
the web browser on PC. The default IP address is 192.168.1.100. You can
get the current Matrix IP address via RS-232 control. Send the ASCII
command “ r ipconfig!” through a Serial Command tool, then you’ll get the
feedback information as shown below.
