5.3
Connecting to the Matrix
1. Connect the desired HDMI input sources.
2. Connect the desired HDMI display devices.
3. Connect the desired control devices: TCP/IP, RS-232 or IR IN.
4. Connect audio devices to either the Coaxial or L/R audio output ports.
5. Connect the 12V DC power supply.
5.4
Using the Matrix
5.4.1 Power LED and Standby Mode
The Power LED provides the following indications:
Color
Description
Red
The Matrix is active and fully controllable.
Off
The Matrix is in standby mode, this state can be
changed by using API commands, IR Remote or
Web GUI.
5.4.2 Selecting Inputs
Select the signal source for the output port by pressing the OUT 1 / OUT 2 /
OUT 3 / OUT 4 button on the front panel (cyclic selection mode) until the
corresponding input source LED lights up.
