3 / 21
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
220mm (W)×105mm (D)×44mm (H)
Weight
792g
Power Supply
Input: AC100~240V 50/60Hz
Output: DC12V/2.5A (Locking connector)
Power Consumption
10W (Max), 1.56W (Standby mode)
Operating
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)
Resolution /
Cable Length
4K60 -
Feet / Meters
4K30 -
Feet / Meters
1080P60 -
Feet / Meters
HDMI IN / OUT
10ft / 3M
30ft / 10M
42ft / 15M
The use of “Premium High Speed HDMI” cable is highly recommended.
5. Operation Controls and Functions
5.1
Front Panel
Name
Function Description
IR Receiver Window
IR input for remote control of the Matrix.
POWER LED
Red LED indicates that the unit is powered on.
OUT 1/2/3/4 button
▪ Short press to circularly select the desired input source
IN 1/2/3/4 for OUT 1/2/3/4 port output.
▪ Press OUT 1/2/3/4 button for 3 seconds to switch Scaler
mode for the OUT 1/2/3/4 port.
IN 1/2/3/4 LED
When IN 1/2/3/4 port is selected as the input channel for
OUT 1/2/3/4 port, the corresponding green LED will be on.
