1. Introduction
DVDO-Matrix-44 is a high performance 4×4 HDMI 4K 18Gbps matrix that can
switch any of four HDMI 2.0 sources to four HDMI 2.0 displays. Each input
and output supports up to 4K60 444 resolution and HDCP 2.2. The outputs
can be individually scaled (4K→1080p). De-embedded audio can be output
through analog L/R and coaxial audio output ports. The ARC function can
return display device audio to coaxial port output only. Advanced EDID
management is supported. This Matrix supports 18Gbps bandwidth and the
additional features with latest HDMI standards. It can be controlled from the
front panel, RS-232, IR remote, or TCP/IP.
2. Features
☆ HDMI 2.0, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
☆ Video resolution is up to 4K2K@60Hz (YUV 4:4:4)
☆ Support 18Gbps video bandwidth
☆ Four outputs can be individually scaled (4K→1080p)
☆ De-embedded audio to analog L/R and Coaxial ports output
☆ ARC audio return to the coaxial ports output only
☆ Built-in Web GUI for TCP/IP control
☆ Advanced EDID management supported
☆ Four methods of control: Front panel, RS-232, IR remote and TCP/IP
☆ Compact design for easy and flexible installation
3. Package Contents
Qty
Item
1
4×4 HDMI 4K 18Gbps Matrix
1
12V/2.5A Locking Power Adapter
1
IR Remote
2
Mounting Ears
1
38KHz IR Receiver Cable (1.5 meters)
1
3pin-3.81mm Phoenix Connector
4
Machine Screws (KM3*4)
1
User Manual
