18 / 21
s clear preset z!
Clear stored preset z scenarios,z=1~8
clear preset 1
r preset z!
Get preset z information, z=1~8
video/audio crosspoint
s baud rate xxx!
Set the serial port baud rate of RS02 module,
z=(115200,57600,38400,19200,9600,4800)
Baudrate:115200
r baud rate!
Get the serial port baud rate of RS02 module
Baudrate:115200
s id z!
Set the control ID of the product, z=000~999
id 888
Output Setting
s in x av out y!
Set input x to output y,x=1~4,y=0~4(0=all)
input 1 -> output 2
r av out y!
Get output y signal status y=0~4(0=all)
input 1 -> output 1
input 2 -> output 2
……
input 4 -> output 4
s out y stream z!
Set output y stream on/off, y=0~4(0=all) z=0~1
(0:disable,1:enable)
Enable out 1 stream
Disable out 1 stream
r out y stream!
Get output y stream status, y=0~4(0=all)
Enable out 1 stream
s hdmi y scaler z!
Set hdmi output y port output scaler mode
,
y=0~4
(0=all), z=1~3(1=bypass,2=4k->1080p,3=Auto)
hdmi 1 set to bypass mode
r hdmi y scaler !
Get hdmi output y port output mode y=0~4(0=all)
hdmi 1 set to bypass mode
s hdmi y hdcp z!
Set hdmi output y port hdcp status y=0~4(0=all)
z=0~1(1=active,0=off)
hdmi 1 hdcp active
r hdmi y hdcp!
Get HDCP status of HDMI out y, y=0~4(0=all)
hdmi 1 hdcp active
Audio Setting
s hdmi y arc z!
Turn on/off arc of HDMI output y ,y=0~4(0=all)
z=0~1(z=0,off,z=1 on)
hdmi output 1 arc on
hdmi output 1 arc off
r hdmi y arc!
Get the arc state of HDMI output y,y=0~4(0=all)
hdmi out1 arc on
EDID Setting
r edid in x!
Get EDID status of the input x
,
x=0~4(0=all inputs)
IN1 EDID: 4K2K60_444,
Stereo Audio 2.0
IN2 EDID: 4K2K60_444,
Stereo Audio 2.0
IN3 EDID: 4K2K60_444,
Stereo Audio 2.0
IN4 EDID: 4K2K60_444,
Stereo Audio 2.0
r edid data hdmi y!
Get the EDID data of the hdmi output y port, y=1~4
EDID : 00 FF FF FF FF FF
FF 00 ………
