The ASCII command list about the product is shown as below.
ASCII Command
Serial port protocol: Baud rate:115200 (default), Data bits: 8bit, Stop bits:1, Check bit: None
TCP/IP protocol port: 8000
The x, y, z and XXX are parameters. ! is the delimiter.
ASCII Command
Function Description
Feedback
Power
s power z!
power on/off the device,z=0~1(z=0 power off, z=1
power on)
power on
System Initializing...
Initialization Finished!
power off
r power!
get current power state
power on /power off
s reboot!
reboot the device
Reboot…
System Initializing...
Initialization Finished!
System Setting
help!
Lists all commands
r type!
Get device model
HDP-MXB44P
r status!
Get device current status
Get the unit all status:
power, beep, lock, in/out
connection, video/audio
crosspoint, edid, scaler,hdcp,
network status
r fw version!
Get Firmware version
MCU FW version x.xx.xx
r link in x!
Get the connection status of the x input port,
x=0~4(0=all)
HDMI IN1: connect
r link out y!
Get the connection status of the y output port,
y=0~4(0=all)
HDMI OUT1: connect
s reset!
Reset to factory defaults
Reset to factory defaults
System Initializing...
Initialization Finished!
s beep z!
Enable/Disable buzzer function,z=0~1(z=0 beep
off, z=1 beep on)
beep on / beep off
r beep!
Get buzzer state
beep on / beep off
s lock z!
Lock/Unlock front panel button,z=0~1(z=0 lock
off,z=1 lock on)
panel button lock on
panel button lock off
r lock!
Get panel button lock state
panel button lock on/off
s save preset z!
Save switch state between all output port and the
input port to preset z,z=1~8
save to preset 1
s recall preset z!
Call saved preset z scenarios,z=1~8
recall from preset 1
