2
2. Specifications
Video Input
Input
(2) HDBaseT, (2) HDMI
Input Connector
(2) RJ45, (2) Type-A female HDMI
HDMI Input Resolution
Up to 4K@60Hz 4:4:4, HDR10, Dolby Vision
HDBaseT Input Resolution
Up to 4K@60Hz 4:2:0
Video Output
Output
(2) HDBaseT, (2) HDMI
Output Connector
(2) RJ45, (2) Type-A female HDMI
HDMI Output Resolution
Up to 4K@60Hz 4:4:4, HDR10, Dolby Vision
Supports 4K to 1080p down-scaling.
HDBaseT Output Resolution
Up to 4K@60Hz 4:2:0.
Supports 4K to 1080p down-scaling.
HDMI Audio Signal
LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital®
Plus, DTS:X™, and DTS-HD® Master Audio™ pass-through.
Audio Output
Output
(1) Stereo analog audio, (1) SPDIF audio
Output Connector
(1) 3.5mm jack, (1) Toslink connector
Analog L+R Audio Format
PCM 2CH
Digital SPDIF Audio Format
PCM, Dolby Digital, DTS, DTS-HD
Max Output Level
Stereo: 2.0Vrms ± 0.5dB. 2V = 16dB headroom above -10dBV
(316mV) nominal consumer line level signal.
SPDIF: ±0.05dBFS
Frequency Response
20Hz to 20kHz, ±1dB
THD+N
< 0.05%, 20Hz to 20kHz bandwidth, 1kHz sine at 0dBFS level (or
max level)
SNR
Stereo: >80dB, 20Hz to 20kHz bandwidth
SPDIF: > 90dB, 20Hz to 20kHz bandwidth
Crosstalk Isolation
Stereo: < -80dB, 10kHz sine at 0dBFS level (or max level before
clipping)
SPDIF: < -70dB, 10KHz sine at 0dBFS level (or max level before
clipping).
L-R Level Deviation
Stereo: < 0.05dB, 1kHz sine at 0dBFS level (or max level before
clipping)
Output Load Capability
Stereo: 1KΩ and higher (Supports 10x paralleled 10KΩ loads).
Noise Level
Stereo: -80dB.
SPDIF: -90dB
