27
8.2
RS232 Commands
After set all needed input and output devices according to the RS232 connection
diagram, please install the RS232 control software (e.g. docklight) into the control PC
to send RS232 command.
After installing the RS232 control software, please set the parameters of COM number,
bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send
command in command sending area.
When controlling the switcher, the serial port settings for all RS232 commands is:
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
The matrix switcher can be controlled by sending the following RS232
commands, and the command ending is “<CR><LF>”.
8.2.1 System Setting
Command
Description
Command Example and
Feedback
>SetPowerOn [param1]
Enter/ exit standby mode.
[param1] = En, Dis
En - Power on.
Dis - Standy mode.
>SetPowerOn En
>SetPowerOn Dis
<PowerOn False
<PowerOn True
>GetFirmwareVersion
Get the firmware version.
<V1.0.0
>SetFactoryReset
Reset to factory default.
<FactoryReset_True
>SetReboot
Device reboot.
<Reboot_True
>GetStatus
Get system working status.
…
>SetRS232Baudrate
[param1]
Set the serial baud rate of matrix switcher
to [param1]. [param1] = 1~7
1 - 115200 2 - 57600 3 - 38400
4 - 19200 5 - 9600 6 - 4800
7 - 2400
>SetRS232Baudrate 3
<RS232Baudrate 9600
>GetRS232Baudrate
Get the baud rate of switcher.
<RS232Baudrate 9600
>SetKeyboardLock
[param1]
Lock/unlock front panel buttons.
[param1] = En, Dis
En - Lock
Dis - Unlock
>SetKeyboardLock En
>SetKeyboardLock Dis
<KeyboardLock True
<KeyboardLock False
>GetKeyboardLock
Get the front panel locking status.
<KeyboardLock True
<KeyboardLock False
>SetSignalDet [param1]
Set the input signal detection method.
[param1] = 5V, TMDS.
>SetSignalDet TMDS
>SetSignalDet 5V
