DVDO -Matrix-22 handleiding
Handleiding
Je bekijkt pagina 7 van 9
5/6
Power on the product or set it to standby status.
OUTPUT A
1/2: Select input 1 or input 2 source signal to
OUTPUT A port.
: Select circularly input 1 or input 2 source
signal to OUTPUT A port.
OUTPUT B
1/2: Select input 1 or input 2 source signal to
OUTPUT B port.
: Select circularly input 1 or input 2 source
signal to OUTPUT B port.
Notice: ①: The power LED on the front panel will illuminate in
red when the product is working or on standby.
②: The input source LED on the front panel will illuminate in
blue when OUTPUT A or OUTPUT B is selected by an input
source.
6. IR Remote
7. FAQ
Q: Does this product require an HDMI cable length for the connection interface?
A: According to HDMI input / output cable length test, the longest HDMI cable
for 4K2K@60Hz / 8 bit YCbCr 4:4:4 is 5m, the longest HDMI cable for 4K2K@
30Hz / 8-bit is 10m, the longest HDMI cable for 1080p@60Hz / 8-bit is 15m.
The use of “Premium High Speed HDMI” cable is highly recommended.
For using the IR remote, the best distance is 0~7m and the best angle is ± 45°.
