3/6
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
144mm (W)×59.5mm (D)×18mm (H)
Weight
208g
Power Supply
Input: AC100~240V 50/60Hz
Output: DC5V/1A (US/EU standard, CE/FCC/UL certified)
Power Consumption
2.7W
Operating
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)
5. Operation Controls and Functions
Front Panel
Number
Name
Function Description
1
POWER LED
Power LED indicator.
Notice: The power LED illuminates in red when the product
is working or on standby.
2
OUTPUT A
Press the OUT A button to select 1 or 2 input source, the
corresponding LED indicator will illuminate in green.
3
OUTPUT B
Press the OUT B button to select 1 or 2 input source, the
corresponding LED indicator will be illuminated in green.
4
EDID AUTO/
COPY/STD
▪ AUTO: When the selector is dialed to the AUTO position,
the product will compare OUT A and OUT B EDID setting
and output the lowest resolution to source devices, then the
source devices will send the signal to all HDMI outputs.
