06-
Operate
Output
Operate
Output
Operate
Output
Up
Down
Left
Operate
Output
Operate
Output
Operate
Output
Right
Zoom +
Zoom -
3.2
Description of Rotary Joystick
Joystick [Up, Down, Left, Right]: Control the PTZ to turn up, down, left and tight.
Joystick [rotate left and right]: Rotate the joystick to zoom function, rotate right to zoom +, zoom
4.
Controller Connection & Control Device
> 255 Cameras respectively adopt RS485 Pelco protocol
> 7 Cameras respectively provided by Visca via RS422 group
> 255 Cameras adopt Visca Over IP protocol respectively
> A total of 255 cameras are controlled by cross-protocol mixing
> Add Network Camera
(1)
Press the enter button to enter the cameras ID
(2)
Set to select IP Visca (Onvif, Sony Visca) protocol
(3)
Press [Enter] button to save (After input enter)
(4)
Enter the IP address of the camera
(5)
Enter port number
(6)
Enter camera username, password
(7)
IP Visca (Sony Visca) protocol does not need to
input camera username, password
Port:
IP
control
port
Sony Visca defaults to 52381
IP Visca defaults to 1259
ONVIF default to 2000 or 80
If you have multiple Visca Over IP
cameras different manufactures,
you may have to set different
