1 Packing List
Name
Quantity
Name
Quantity
Wireless Receiver Box
1
Power Adapter
1
Antenna
2
User Manual
1
2 Appearance and Interface
No.
Name
No.
Name
1
DC 12V Interface
2
LAN Interface
3
Power Indicator
-
-
3 Product Features
Wireless Transmission
Stable and reliable wireless transmission, 2x2 MIMO, with a maximum
transmission rate of 300Mbps, strong penetration, and a transmission distance
of up to 200 meters. Equipped with automatic search and intelligent
configuration functions, with high transmission efficiency.
One to More Transmission
A wireless receiver box can be paired with multiple (up to 8) wireless cameras to
form a wireless transmission scheme. The wireless receiver box is connected to
the network through the switch and can directly pull the network flow of the
corresponding camera. Without wiring, the machine position arrangement can
be easily completed.
⚫ Operating this equipment in a residential environment may cause radio
interference.
⚫ To avoid damage receiver box, do not use without installing the antenna!
⚫ When using the camera with wireless connection, it is prohibited to
simultaneously connect the camera to the LAN network port. Doing so may
result in a network loop, leading to network disconnection.
4 Product Specifications
Wireless Features
Wireless Frequency
5.18Ghz~5.24Ghz
5.745Ghz~5.825Ghz
Transmission Power
27dBm
Antenna Mode
2*2MIMO
Channel Bandwidth
20/40MHz
Modulation Mode
OFDM
Data Rate
300Mbps (max.)
Network Mode
Point to Point, Point to Multipoint
Penetration
1~2 walls
Transmission Distance
200M
Protocol
802.11a/n
Interface/Indicator
Network Interface
1 x LAN: 10M/100M Adaptive Ethernet Port
Power Interface
JEITA type (DC IN 12V)
Power Indicator
Red
General Specifications
Input Voltage
DC 12V
Input Current
1.0A
Operating Temperature
0°C~40°C
Storage Temperature
-40°C~60°C
Power Consumption
12W (max.)
Dimension
123mm x 88mm x 30mm (not include antenna)
Net Weight
About 0.3Kg (not include antenna)
5 Product Dimensions
Unit: mm
123
Warning
LANDC 12V
88
185.2
