12
PTZ back to the preset position.
6) PTZ/OSD
Move the cursor to dropdown menu, select and
click “OSD” to open the on-screen menu and do
menu settings on the interface.
C. Language Selection
Select “Simplified Chinese”, “English”, “Russian”
or “Traditional Chinese” to change the language
of the webpage.
6.3 Video Settings
1) Video Format
Support 50Hz (PAL) and 60Hz (NTSC) formats.
2) Encode Level
Support baseline, mainprofile and highprofile.
3) Encode Codec
Support H264, H265 and MJPEG.
4) Resolution
First stream support 3840x2160, 1920x1080,
1280x720, 1024x576, 960x540, 640x480, 640x360.
Second stream support 640x360, 480x272,
320x240, 320x180; The bigger the resolution,
the clearer the image, and the larger the code
stream, the more network bandwidth will be
taken.
5) Bit Rate
You can specify the bit rate, the larger of the bit
rate, the clearer of the image. The configuration
of the bit rate needs to be combined with the
network bandwidth. When network bandwidth is
narrow and the bit rate is configured larger, the
video stream cannot be transmitted normally,
and the visual effect will be worse.
6) Frame Rate
You can specify the size of the frame rate, the
greater the frame rate, the smoother the image,
the smaller the frame, the more sense of beating.
7) I Key Frame Interval
Set the interval between two I frames, the bigger
the interval, the slower the response when
opening the image for the first time.
8) Bit Rate Control
Two modes for bit rate control:
CBR (Constant Bit Rate): Video coder will be
coding according to the preset speed.
VBR (Variable Bit Rate): Video coder will adjust
the speed based on preset speed to gain the best
image quality.
9) Slice Split Enable
Enable or disable the Slice Split function.
10) Split Mode
Split Mode Fixed bytes.
11) Slice Size
Size for slice.
English
Language
中文(简)
中文(繁)
Video Settings
50Hz
Video Format
mainprofile
Encode Level
First Stream
H264
Encode Codec
3840x2160
Resolution
8096
Bit Rate
25
Frame Rate
fps
blocks/bytes
blocks/bytes
25
I Key Frame Interval
CBR
Bit Rate Control
Second Stream
H264
320x240
1024
25 fps
25
CBR
Submit Cancel
Off
Slice Split Enable
Split Mode
32
Slice Size
Encode Codec
Resolution
Bit Rate
Frame Rate
I Key Frame Interval
Bit Rate Control
Slice Split Enable
Split Mode
Slice Size
Off
57600
Fixed bytes
Fixed bytes
