11
6 Web Settings
6.1 Access Camera
Access http://192.168.100.88 to pop up the login
window, then input username (default: admin)
and password (default: admin). After login, it will
show below:
6.2 Control Camera
All pages include two menu bars:
Real Time Monitoring: Video image displaying
with function buttons.
Parameter Setup: Parameter configurating.
A. Video Viewing Window
The video viewing window is same as video
resolution, the bigger the resolution, the bigger
the playing area. Double click the viewing
window to show full screen, double click again, to
return to initialized size.
Status bar in viewing window shown below:
Full screen switch button.
B. PTZ Setup
1) Pan and Tilt Control
The direction arrows and HOME button allow you
to manually drive the camera to desired position.
2) Zoom
Zoom In and Zoom Out buttons allow for wide or
narrow view of the space.
3) Focus
Focus In and Focus Out button allow for fine
manual focus adjustment if the camera has any
auto focusing problems on difficult object. The
Focus Mode can be selected Auto/Manual. When
you select “Manual”, Focus In and Focus Out will
to take effect.
4) PTZ Speeds
Pan speed rate can be set to 1~24, Tilt speed rate
can be set to 1~20. Zoom and Focus speed rate
can be set to 1~7.
5) PTZ Presets
When the PTZ turns to the position that you
would like to return to later, you can set presets
for quick recall. Type a number (0~254) into the
preset box and click “Set” button to save.
When the PTZ turn to other position, input the
preset number and click “Call” button to turn the
Video
Audio
System
Network
Information
Zoom In Zoom Out
Focus In Focus Out
10
10Pan Speed
Tilt Speed
Live
AutoFocus Mode
4:18
Zoom In Zoom Out
Focus In Focus Out
10
Tilt Speed
5
Zoom Speed
Set Call
Preset
PTZ Back
10
Pan Speed
Focus Speed
5
Auto
Focus Mode
