3. Package Contents
①
1 × HDMI 2.1 Test Signal Generator - Analyzer (Built-in lithium
battery)
②
1 × Serial Cable (3.5mm headphone connector to DB9 female
connector, 1m)
③
1 × 5V/2A Power Adaptor
④
1 × User Manual
4. Specifications
Technical
HDMI Compliance
HDMI 2.1
HDCP Compliance
HDCP 2.3/1.4
Video Bandwidth
40Gbps
Video Resolution
Up to 8K@50/60Hz (YUV4:2:0 10-bit)
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth
8/10/12-bit
Audio Formats
Internal HDMI: LPCM 2CH, 48kHz, 16bits
External S/PDIF: LPCM 2/5.1CH, Dolby Digital, DTS 5.1
HDMI Pass-through: LPCM 2/5.1/7.1CH, Dolby Digital,
DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master
Audio, Dolby Atmos, DTS:X
ESD Protection
IEC 61000-4-2:
±8kV (Air-gap discharge) & ±4kV (Contact discharge)
Connection
Input ports
1
×
HDMI In [Type A, 19-pin Female]
1
×
Optical In [S/PDIF]
Output ports
1
×
HDMI Out [Type A, 19-pin Female]
1
×
Optical Out [S/PDIF]
