Operation
100 Operating Instructions 756 D - 00.0 - 06/2024
4.29.1 Programmable marking lamp
Fig. 56: Programmable marking lamp (1)
You can individually correct the position of the marking lamps for each pro-
gram and adapt them to different material thicknesses and applications.
The programmable marking lamp (1) can be
programmed in sewing direction (Y-axis).
The programmable marking lamp (1) automatically adjusts to
the corresponding positioning point: front, center (2) and rear.
The settings for the programmable marking lamp (1) are adjusted at
the control panel ( p. 173).
Important
The Vertical programmable marking lamps
will not be operational unless previously activated in the
Machine config. ( p. 214).
To activate the vertical marking lamps:
(1) - Programmable marking lamp (2) - Positioning point: center
①
②
