DRIVER FEATURES / CARACTERÍSTICAS DEL DRIVER
Voice Coil Diameter /
Diámetro de la Bobina de Voz ............................................................1" / 25.4 mm
Type/
Tipo .................................................... Compression driver with Injection molding ABS horn /
Driver de Compresión con Difisor ABS moldeado por inyección
Diaphragm Material / Material del Diafragma...............................................................Titanium / Titanio
Magnet Material / Material del Imán...................................................................Neodymium / Neodimio
Crossover / Cruce ......................................................................................................................... 6dB/Oct
Horn Diameter /
Diametro del Difusor ................................................................................ 3.26" / 83mm
THIELE & SMALL PARAMETERS/ PARÁMETROS T/S
Equivalent Volume /
Volumen Equivalente ...................................Vas ............................. 10L / 0.35 ft3
Excursion (one way) /
Excursión (1 vía)..................................... Xmax ........................................ 9.2 mm
Free Air Resonance /
Resonancia al Aire Libre ................................Fs ......................................... 135 Hz
Mechanical Factor /
Factor Mecánico..........................................Qms ..............................................5.96
Electrical Factor /
Factor Eléctrico................................................ Qes ........................................... 1.321
Total Factor /
Factor Total...............................................................Qts........................................... 1.011
Mechanical Mass /
Masa Mecánica............................................. Mms ........................................... 9.69g
Mechanical Compliance/
Cumplimiento Mecánico ...................... Cms .................................... 137.435g
Bl Factor /
Factor Bl .......................................................................... Bl ........................................... 4.580
Voice Coil Inductance /
Inductancia de Bobina de Voz......................Le....................................... 4.22mH
Cone Area /
Área de Cono ................................................................. Sd ................................226.98 Cm2
DC Resistance /
Resistencia DC ....................................................... Re ......................................3.4 OHM
Mechanical Mass w/o air/
Masa Mecánica sin Aire
......................................................................Mmd......................................... 7.724g
SPEAKER MEASUREMENTS / MEDIDAS DEL ALTAVOZ
Overall Diameter /
Diámetro Total .................................................................................... 8.6" / 218 mm
Overall Depth /
Profundidad Total ...................................................................................... 9.4" / 238 mm
Overall Heigth /
Profundidad Total ..................................................................................12.3" / 313 mm
COLORS AVALIABLE / DISPONIBILIDAD DE COLORES
Matte Black /
Negro Mate.................................................................................................NXL-X8PRO/BK
Glossy White /
Blanco Brillante ...................................................................................... NXL-X8PRO/WH
NXL-X8PRO
9
PRO-HY8.4B BUILT IN
1” TITANIUM COMPRESSION
HORN DRIVER WITH
NEODYMIUM MAGNET
CS-8
Cover Included
