Tools Needed
Vinyl Seal Installation (Cont’d.)
(Notching the Hinge-Side Vinyl)
PRISM PLUS Shower Enclosure Manual Ver 2 012020
25
© 2020 DreamLine® All Rights Reserved
hinge
panel
door
Fig 19
Notch bottom of vinyl
to t around back side
of the hinge
Slice the soft vinyl ap
with a razor knife where
the hinge and glass meet
Notch vinyl to
t around back
side of hinge
Slit soft
vinyl ap
7/8”
7/8”
Notch top and bottom of
vinyl to t around back
of hinge and around the
sweep vinyl.
1 2
3
NOTE
Notches in the vinyl should
be approximately 7/8”
Slice the soft vinyl ap
with a razor knife where
the hinge and the glass
meet
18
