Tools Needed
Parts Needed
15
PRISM PLUS Shower Enclosure Manual Ver 2 012020
© 2020 DreamLine® All Rights Reserved
NOTE
For installation into an Acrylic threshold:
◾ Drill an Ø1/8”(3mm) hole
and use
the ST4.2 x 40mm Countersunk Screws (#23)
.
For installation into an Tile threshold
◾
Drill a Ø3/16” (4mm) hole up to the stud,
drill an Ø1/8” (3mm) pilot hole into the stud
and use
the ST4.2 x 40mm Countersunk Screws (#23)
.
2
3
1
NOTE
Repeat these steps to install the
panel glass on the opposite
threshold
8
