Installation Steps
Tools Needed
PRISM PLUS Shower Enclosure Manual Ver 2 012020 9
© 2020 DreamLine® All Rights Reserved
© DreamLine
®
All Rights Reserved
© DreamLine
®
All Rights Reserved
Fig 1
34"
36"
38"
40"
Glass Box Code
W1
34"
36"
38"
40"
W2
SHEN-GLP2601-343410
SHEN-GLP2601-363610
SHEN-GLP2601-383810
SHEN-GLP2601-404010
Table A
NOTE: The Stainless Steel U-Channels (#11)
must be installed at the correct dimensions
for the model size indicated in Table A.
!
W2
W1
W1
W2
NOTE
Measure at the bottom
and draw a plumb line up
from the threshold
1
