3. The DreamStone or alternate shower wall material will

be installed over the 1/2” moisture-resistant wall

board and shower floor flange, as shown in the

illustration below.

Example 2

If the shower floor is to be installed in conjunction with a

DreamStone Alcove Wall Kit, the following procedures

must be followed.

1. Install the shower floor following the appropriate

instructions in the Standard Shower Floor Installation

or Barrier-Free Shower Floor and Ramp Installation

section in this manual. The illustration below shows

the ideal shower floor flange to frame work gap of

3/16”.

2. After shower floor installation is complete, refer to

the alcove wall kit manual for more information on

installing alcove wall kits. Follow those instructions

to install the DreamStone Alcove Wall Kit directly to

the stud wall framework.

Example 3

If the shower floor is to be installed in conjunction with

existing moisture-resistant wall board, the following

procedures must be followed.

1. Install the shower floor following the appropriate

instructions in the Standard Shower Floor Installation

or Barrier-Free Shower Floor and Ramp Installation

section in this manual. The illustration below shows

the ideal shower floor flange to existing wall surface

gap of 3/16”.

BK-SB-003

3/16"

1/2"

Existing

Wall

Surface

Shower

Floor

ABS-028a

Side

Panel

Multiple Studs

Top View

Looking Down

3/4” Filler Board for

Shower Door Installation

BK-SB-003

3/16"

1/2"

DreamStone

Wall Panel

Moisture

Resistant

Wallboard

(866) 731-2244

DreamLine – DreamStone

Installation Procedure
