17 1817 18
EN EN
4
13. Rotate the latch counterclockwise to the stop
position to remove the roller brush from the slot.
Wipe off the dust from the slot and transparent
cover with a dry cloth or tissue. Use scissors to cut
off any hairs and fibers tangled on the roller brush.
14. To replace the roller
brush, open the side
cover of the roller brush,
replace it with a new one,
and press the side cover
back in place.
12. Gently tap the vacuum
filter to remove dust and
debris from the gaps.
Rinse the vacuum filter
with clean water, rotating
it 360° while cleaning.
Allow it to dry completely
for at least 24 hours.
16. Rinse and clean the
roller brush. Stand it
upright to dry for at least
24 hours.
15. Use a coin as illus-
trated to rotate the latch
counterclockwise to
remove the roller brush
from the motorized
mini-brush.
9. Press the dust cup
release button to remove
the dust cup. Pull the
pre-filter upwards, rotate
the cyclone system
clockwise, lift it out.
Empty the dust.
10. Rinse the pre-filter,
cyclone system and dust
cup with clean water.
Allow them to dry for at
least 24 hours to ensure
thorough drying before
reinstalling.
11. Press the motor
release button downward
to remove the motor. Pull
the vacuum filter out of
the motor in the direction
shown.
9 10 11
14 15 16
12
13
1
2
3
4
1
2
1 2 3
1. Pour out the dirty water.
Remove the filter and
gently tap it to shake off
any loose dust. Rinse the
filter, tank cover and tank
with clean water. Allow
them to fully dry before
reinstalling.
2. Gently wipe the tube
and the dirt sensor with
a wet cloth before use.
Insert the used water
tank into the bottom of
the main body and tilt it
towards the main body.
3. After removing the clean
water tank, use a coin to
turn the locking knobs on
the roller brush cover and
detach the cover. Pull up
the roller brush handle to
remove the roller brush.
4
7 8
5 6
6. Flip the roller brush
cover, pull out the lifting
robotic arm, and push
the scraper to the left
to remove it. Rinse the
scraper with clean water.
Once fully dry, align it
with the slot and push it
to the right to reinstall.
4. Wipe the suction inlet
with a dry cloth or wet
tissue. Do not rinse the
floor brush with water.
5. Use the provided clean-
ing brush to remove hair
or debris tangled around
the roller brush. Rinse the
roller brush with clean
water and allow it to fully
dry before reinstalling.
7. Insert the roller brush
back into place. Align the
roller brush cover with the
floor brush and turn the
locking knobs to secure it.
Align the clean water tank
with the roller brush cover
and press it down until it
clicks.
8. This product uses a removable lithium battery
pack, which is a consumable part. If the battery
life significantly decreases even after proper
charging, replace it as needed. To do so, press
and hold the release buttons on both sides of the
battery pack and slide it out, then insert a new
battery pack.
DMJDL
Note:
• [ÁĂ秷ÖîÍĐÓÁÌÖçĐÁąÁĥÁąĬ溣Đõ溦ìõîĐÓĉÖĉąÁ·õììÁî½Á½潻
• çÁ§î§ĉîÁÁ½Á½潻[ÁĂ秷ÖîÍĐÓÁ¶ąĕĉÓąõççÁąÁĥÁąĬ溣Đõ溦ìõîĐÓĉÖĉąÁ·õììÁî½Á½潻
• õîõĐąÖîĉÁĐÓÁĐĕ¶ÁõąĐÓÁ½ÖąĐĉÁîĉõą潻
Note:
• çÁ§îĐÓÁ½ĕĉĐ·ĕçĉîÁÁ½Á½潻
• /ĐÖĉąÁ·õììÁî½Á½Đõ·çÁ§îĐÓÁ·Ĭ·çõîÁĉĬĉĐÁì§î½ĂąÁ瀐ÌÖçĐÁąÁĥÁąĬ溣Đõ溤
ìõîĐÓĉ潻
• /ĐÖĉąÁ·õììÁî½Á½ĐõąÁĂ秷ÁĐÓÁÌÖçĐÁąÁĥÁąĬ溣Đõ溦ìõîĐÓĉ潻
• çÁ§îĦÖĐÓĦ§ĐÁąõîçĬ潾½õîõЧ½½§îĬ·çÁ§îÖîÍĉõçĕĐÖõîĉ潻
• õîõĐĕĉÁ¶ąĕĉÓÁĉõąÌÖîÍÁąĉĐõ·çÁ§îĐÓÁÌÖçĐÁą潻
4
13. Rotate the latch counterclockwise to the stop
position to remove the roller brush from the slot.
Wipe off the dust from the slot and transparent
cover with a dry cloth or tissue. Use scissors to cut
off any hairs and fibers tangled on the roller brush.
14. To replace the roller
brush, open the side
cover of the roller brush,
replace it with a new one,
and press the side cover
back in place.
12. Gently tap the vacuum
filter to remove dust and
debris from the gaps.
Rinse the vacuum filter
with clean water, rotating
it 360° while cleaning.
Allow it to dry completely
for at least 24 hours.
16. Rinse and clean the
roller brush. Stand it
upright to dry for at least
24 hours.
15. Use a coin as illus-
trated to rotate the latch
counterclockwise to
remove the roller brush
from the motorized
mini-brush.
9. Press the dust cup
release button to remove
the dust cup. Pull the
pre-filter upwards, rotate
the cyclone system
clockwise, lift it out.
Empty the dust.
10. Rinse the pre-filter,
cyclone system and dust
cup with clean water.
Allow them to dry for at
least 24 hours to ensure
thorough drying before
reinstalling.
11. Press the motor
release button downward
to remove the motor. Pull
the vacuum filter out of
the motor in the direction
shown.
9 10 11
14 15 16
12
13
1
2
3
4
1
2
Care & Maintenance Care & Maintenance
