3
3
.
.
2
2
C
C
o
o
n
n
n
n
e
e
c
c
t
t
i
i
n
n
g
g
E
E
t
t
h
h
e
e
r
r
n
n
e
e
t
t
C
C
a
a
b
b
l
l
e
e
(
(
s
s
)
)
Refer to the following steps to attach the Ethernet cable and waterproof head. (Take
VigorAP 920RP as an example.)
1. Remove the cable cover for Ethernet Port (e.g., Port 1 PoE In).
2. Before connecting, verify that the cable has a rubber seal and that it is not
damaged.
Note
To prevent the enclosure from water leakage, make sure the
Ethernet cable gland and the rubber gasket are present and installed
properly.
3. Inserting RJ-45 connector into the port.
4. Use an adjustable wrench and tighten the thread-lock sealing nut with torque 10
kgf-cm.
Note
Do not pull the cable backwards; the force might break the plug.
