2. CONTENTS
- 3 -
- 10 -
Depending on manufacture and model, some engine components do change. Please check with
Autodata or the manufacturer’s data before use.
1. TITLE PAGE
1.1 INTRODUCTION.......................................................................................................... 2
1.2 REVISION HISTORY .................................................................................................. 2
1.3 UNDERSTANDING THIS GUIDE................................................................................. 2
1.4 COPYRIGHT NOTICE .................................................................................................2
2. CONTENTS
2.1 CONTENTS ....................................................................................................................3
3. GUARANTEE
3.1 GUARANTEE ............................................................................................................... 4
4. GENERAL PRODUCT INFORMATION
4.1 GENERAL PRODUCT INFORMATION ....................................................................... 5
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR USE
Personal safety........................................................................................................... 6
6. CONTENTS
6.1 PARTS DRAWING AND LISTING ............................................................................... 7
7. APPLICATION
7.1 PRODUCT APPLICATION AND COMPATIBILITY LISTING ...................................... 8
8. PREPARATION
8.1 ADVISORIES BEFORE USE ...................................................................................... 9
9. PROCEDURE AND APPLICATION GUIDE
9.1 APPLICATION GUIDANCE........................................................................................ 10
10. EXPLANATION OF SYMBOLS
10.1 EXPLANATION OF SYMBOLS .................................................................................. 11
9. PROCEDURE AND APPLICATION GUIDE
Please note images are for guidance only and subject to change.
A. Balance shaft sprocket locking x2
The balance shaft sprockets and chain are located at the rear of the engines. To gain access
the flywheel must be removed.
• Engine at TDC number 1 cylinder.
• Camshaft locking tools (C) fitted in place to lock the
camshafts.
• Ensure balance shaft timing marks align.
• Fit Balance shaft holding tools as described by Manufacturer
instructions to secure the timing position.
B.Valve Timing Chain
Tensioner pins x 2
Component (B) is used to lock and hold the timing chain and
balance shaft chain tensioners in their fully retracted position.
• Push tensioner fully in (i)
• Insert locking pin (ii)
C. Crankshaft Pulley Holding Tool
Component d is used to hold the crankshaft front
pulley while loosening or torqueing the pulley fixing
bolt. See manufacturer data for tightening torque.
Use a ½” breaker bar or similar to hold (D).
Camshaft Holding & Alignment Tools
Component (C) is made up of two camshaft
locking tools that are designed to bolt together
on the engine to lock the camshafts.
• Set engine to TDC number 1 cylinder.
• Ensure timing marks on crankshaft sprocket
and camshaft sprockets align (See manufacturer data).
• Fit Camshaft Locking tool (C) as shown.
• Tighten the holding bolts in the order shown to hand tight only.
