4. GENERAL PRODUCT INFORMATION
This product is designed to be used correctly and with care for the purpose for which it is intended.
No liability is accepted by Draper Tools Limited for incorrect use or application of any of our
products, and Draper Tools Limited cannot be held responsible for any damage to personnel,
property or equipment when using this product. Incorrect use will also invalidate any warranty.
The applications database and any instructional information provided has been designed to offer
general guidance for a particular product’s use and while all attention is given to the accuracy of
the data, no project should be attempted without referring first to the manufacturer’s technical
documentation (workshop or instruction manual) or the use of a recognised authority such as
Autodata.
It is our policy to continually improve our products and thus we reserve the right to alter
specifications and components without prior notice. It is the responsibility of the user to ensure the
suitability of the product and information prior to use.
7. APPLICATION
- 5 -
- 8 -
The 19156 has been developed as a camshaft sprocket puller and balance shaft tool for the
vehicles listed below. Designed to allow the user to turn the engine safely and also used to remove
the camshaft sprocket off the tapered mounting on the camshaft. Supplied with a balance shaft
locking tool.
Used on the following Vehicles:
Audi A6 2005 - 2015
Audi Q3 2011 - 2015
Audi Q5 2008 - 2016
Audi TT 2008 - 2014
Seat Toledo 2009 - 2015 TDI CR FR
Seat Alhambra 2005 - 2015 TDI PD
Seat Altea/Altea XL 2009 - 2015 TDI CR
Seat Exeo 2009 - 2013 TDI PD Ecomotive
Seat Ibiza 2009 - 2015 TDI CR Ecomotive
Seat Leon 2009 - 2013 TDI CR Freetrack
Skoda Fabia II 2010 - 2015 TDI CR FR/Sport
Skoda Octavia II 2008 - 2013 vRS TDI CR
Skoda Praktik 2010 - 2015 TDI CR GreenLine
Skoda Rapid 2012 - 2015 TDI CR/BlueMotion/Technology
Skoda Roomster 2010 - 2015 TDI CR GreenLine II
Skoda Superb II 2005 - 2016 TDI CR BlueMotion
Skoda Yeti 2009 - 2016 TDI CR BlueMotion Technology
Volkswagen Amarok 2010 - 2017 TDIe CR
Volkswagen Beetle 2011 - 2015 BiTDI CR 400
Volkswagen Caddy 2010 - 2015 BiTDI CR 420
Volkswagen CC 2012 - 2017
Volkswagen Crafter 2011 - 2017
Volkswagen Eos 2008 - 2015
Volkswagen Golf 2008 - 2015 TDI CR 340
Volkswagen Jetta 2008 - 2015 TDI CR BlueMotion/Technology
Volkswagen Jetta 2011 - 2015 TDI CR/BlueMotion Technology
Volkswagen Passat 2003 - 2015 Blue TDI CR
Volkswagen Polo 2009 - 2014 TDI PD BlueMotion
Volkswagen Scirocco 2008 - 2014 TDI CR 4Motion Achleitner
Volkswagen Sharan 2005 - 2015 TDI CR 4x2
Volkswagen Tiguan 2007 - 2016 GTD CR
Volkswagen Touran 2010 - 2015 BiTDI CR
Volkswagen Transporter T5 2009 - 2015
Engine Codes:
1.2cc - CFWA
1.6cc - CAYB, CAYC, CAYA, CLNA, CAYD, CAYE
2.0cc
CFFA, CFFB, CFFE, CFGB, CFGC, BRT, BVH, CEGA, CFHC, CFJA, CAGA, CAGC, CAHA,
CGLB, CJCA, CJCC, CFHD, CLCB, CFHF, CLCA, BSS, CBBB, CLJA, BMP, CFHA, CBDB,
CFJB, CFCA, CAAA, CAAB, CBAC, CBAA, CAHB, CGLC, CGLD, CJCB, CJCD, CMFA,
CMFB, CGLA, BLB, BNA, BPW, BRC, BRD, BRE, BRF, BVA, BVF, BVG, CFGD, CLLB,
CFHB, CBAB, CAGB, CMGB, CAAC, CAAD, CAAE, CCHA, CCHB, CDCA, CNEA, CSHA,
CDBA, BKP, BMA, BMR, BUZ, BVE, BWV, CBBA, CFFD, CNFB, CFHE, CKUB, CKTB,
CKTC, CKUC, CSLB, CSNA, CJAA, CBDA, CLLA, BGW, BHW, CBDC, CMEA, CGLE
Audi A1 2010 - 2015
Audi A3 2008 - 2013
Audi A4 2004 - 2016
Audi A5 2008 - 2015
