– 6 –
4.2 Using the Torque Wrench
Important:
• Always use the correct size socket.
• Apply a steady slow force on the grip handle.
When the required torque is reached, this will be
indicated by the following:
− Audible click: The click will be quieter at lower
torque settings.
− Touch: The handle will be felt to “break away”
at the point of the set torque.
− Visually: The handle will be seen to “break away”
at the point of the set torque.
Note: Responses may be less perceptible at
lower torques.
WARNING!
Once the set torque is reached,
DO NOT continue to turn the torque wrench
as this will deliver an incorrect torque and may
damage the parts.
1. Select the required socket or bit and adaptors as
appropriate and t onto the square drive.
2. Set the adjustment direction by moving the lever (2)
on the back of the wrench head:
− To rotate the ratchet head clockwise, move the
switch to the right position.
− To rotate the ratchet head anticlockwise,
move the switch to the left position.
3. Set the wrench torque; see section 4.1.
4. Place the bit or socket onto the xing and apply
a slow steady force in the desired direction.
5. When the set torque has been reached, the tool will
exhibit an audible, tangible and visual response.
6. Carefully remove the wrench from the xing.
4. Operating Instructions
mN/m
millinewton-
metre
cN/m
centinewton-
metre
N/m
newton-
metre
daN/m
decanewton-
metre
cm/kg
centimetre-
kg
m/kg
metre-
kg
in-oz
inch-
ounce
in-lb
inch-
pound
ft-lb
foot-
pound
1mN/m
1cN/m
1N/m
1daN/m
1
10
1000
10000
0.1
1
100
1000
0.001
0.01
1
10
0.0001
0.001
0.1
1
0.0102
0.102
10.2
102
0.000102
0.00102
0.102
1.02
0.1416
1.416
141.6
1416
0.00885
0.0885
8.85
88.5
0.000738
0.00738
0.738
7.38
1cm/kg
1m/kg
98
9810
9.8
981
0.098
9.81
0.0098
0.98
1
100
0.01
1
13.9
1390
0.868
86.8
0.0723
7.23
lin-oz
lin/lb
lft-lb
7.06
112.9
1355
0.706
11.29
35
0.00706
0.1129
1.355
0.0007
0.01129
0.1135
0.072
1.152
13.8
0.00072
0.0115
0.138
1
0.063
0.0052
16
1
0.083
192
12
1
4.3 Conversion Chart
