2. CONTENTS
- 3 -
- 10 -
Depending on manufacture and model, some engine components do change. Please check with
Autodata or the manufacturer’s data before use.
1. TITLE PAGE
1.1 INTRODUCTION.......................................................................................................... 2
1.2 REVISION HISTORY .................................................................................................. 2
1.3 UNDERSTANDING THIS GUIDE................................................................................. 2
1.4 COPYRIGHT NOTICE .................................................................................................2
2. CONTENTS
2.1 CONTENTS ....................................................................................................................3
3. GUARANTEE
3.1 GUARANTEE ............................................................................................................... 4
4. GENERAL PRODUCT INFORMATION
4.1 GENERAL PRODUCT INFORMATION ....................................................................... 5
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR USE
Personal safety........................................................................................................... 6
6. CONTENTS
6.1 PARTS DRAWING AND LISTING ............................................................................... 7
7. APPLICATION
7.1 PRODUCT APPLICATION AND COMPATIBILITY LISTING ...................................... 8
8. PREPARATION
8.1 ADVISORIES BEFORE USE ...................................................................................... 9
9. PROCEDURE AND APPLICATION GUIDE
9.1 APPLICATION GUIDANCE........................................................................................ 10
10. EXPLANATION OF SYMBOLS
10.1 EXPLANATION OF SYMBOLS .................................................................................. 11
9. PROCEDURE AND APPLICATION GUIDE
Please note images are for guidance only and subject to change.
VARIABLE CAMSHAFT TIMING LOCKING AND SETTING TOOLS 1&2
Used to set up the Variable Camshaft Timing pulleys (VCT). The special tool set 829052 is
used in conjunction with 829051 engine timing kit to assemble the VCT (Variable Camshaft
Timing) pulleys in to their camshafts at TDC.
After assembly of the camshaft drive belt, belt tensioner, front cover, oil seal and crankshaft
front pulley with the crankshaft and camshaft still locked at TDC fit components 1&2 as
shown and tighten bolts (1) to 10Nm. Turn the inlet tool anti-clockwise and the exhaust tool
clockwise to remove any play. Tighten the VCT fixings (2) to the correct torque as described
by OEM instructions.
N.B: refer to OEM data and information for full instruction.
