- 5 --16 -
4. INTRODUCTION
4.1 SCOPE
Professional style wood jointing for creating solid joints in soft & hard wood, ply board, MDF &
most processed timbers. As part of our core range, this product is suitable for enthusiasts and
tradespeople alike. Any other application other than what it was intended for is considered misuse.
4.2 SPECIFICATION
Stock No...............................................................................................................................83611
Part No. ........................................................................................................................ PT8100SF
Motor:
Rated voltage........................................................................................................... 230V~
Rated frequency......................................................................................................... 50Hz
Rated input................................................................................................................ 900W
Revolutions per minute (no load) ..................................................................... 11,000min
-1
Blade:
Diameter .................................................................................................................100mm
Bore ..........................................................................................................................22mm
Thickness.................................................................................................................4.0mm
Teeth .................................................................................................................................6
Cutting depth .................................................................................................................... 0-20mm
Angle adjustment................................................................................................................... 0-90º
Sound pressure level........................................................................................................ 87dB(A)
Sound power level............................................................................................................ 98dB(A)
Vibration level....................................................................................................................2.7m/s2
Weight (machine only)...........................................................................................................3.2kg
* Continuous A-Weighted Sound Pressure Level at the workstation in accordance to and declared
according to EN60745.
** The typical A-weighted noise level determined according to EN60745.
†
When sawing in wood.
4.3 HANDLING AND STORAGE
– Care must be taken when handling this product.
● Dropping this power tool could have an effect on its accuracy and could also result in
personal injury. This product is not a toy and must be respected.
– Environmental conditions can have a detrimental effect on this product if neglected.
● Exposure to damp air can gradually corrode components.
● If the product is unprotected from dust and debris, components will become clogged.
● If not cleaned and maintained correctly or regularly, the machine will not perform at its best.
9. MAINTENANCE AND TROUBLESHOOTING
Sliding action stiff or binding.
Poor cutting performance.
1. Saw blade blunt.
2. Saw blade incorrectly
mounted.
3. Incorrect saw blade
selection.
1. Stop machine
immediately. Replace saw
blade.
2. Stop machine
immediately. Remove and
refit saw blade as per
instructions.
3. Seek advice on suitable
saw blades.
Saw vibrates
1. Saw blade distorted.
2. Saw blade incorrectly
mounted.
1. Stop machine
immediately and replace
blade.
2. Stop machine
immediately. Remove and
refit saw blade as per
instructions.
1. Vacuum up sawdust and
lubricate mechanism.
1. Build up of sawdust
9.5 TROUBLESHOOTING GUIDE
Note:
Remove the plug from the socket before carrying out adjustment, servicing or maintenance.
Problem Possible Cause Remedy
Motor does not start.
1. Fuse.
2. Brushes worn.
3. Other.
1. Replace the fuse.
2. Have brushes replaced by
an authorised service
agent.
3. Contact an authorised
service agent.
