6. Identication and Unpacking
6.2 What’s in the Box?
Carefully remove the product from the packaging and
examine it for any signs of damage that may have occurred
during shipment. Before assembling the product, lay the
contents out and check them against the parts shown
below. If any part is damaged or missing, do not attempt to
use the product. Please contact the Draper Helpline;
contact details can be found at the back of this manual.
6.3 Packaging
Keep the product packaging for the duration of the
warranty period in case the product needs to be returned
for repair.
WARNING! Keep packaging materials out of
reach of children. Dispose of packaging
correctly and responsibly and in accordance
with local regulations.
EN
(10) Shampoo inlet hose and lter.
(11) Shampoo tank.
(13) Push handle.
(14) Handle xing knob.
(15) Castors x 2.
(16) Rear wheels x 2.
(17) Flexible vacuum hose.
(18) Shampoo/vacuum control handle grip.
(19) Retractable extension tube.
(20) Shampoo delivery hose (main).
(21) Vacuum attachment for oors and carpets.
(22) Small uid nozzle for sofa and upholstery.
(22.1) Shampoo delivery hose (small uid nozzle).
(23) Large uid nozzle.
(23.1) Shampoo delivery hose (large uid nozzle).
(23.2) Rubber sleeve.
(24) Crevice attachment.
(25) Round brush attachment.
(26) Paper dust bag.
(27) Cartridge lter.
(28) Anti-foam lter.
(29) Hose clips.
(30) Wheel locking pins x 2.
(31) Wheel hub caps x 2.
(32) Wheel washers x 4.
(33) Wheel axle.
(18)
(30)
(31)
(26)
(28)
(27)
(23.1)
(17)
(10)
(22.1)
(23)
(25)
(21)
(24)
(22)(11)
(23.2)
(15)
(16)
(32)
(33)
(14)
(29) (20) (19) (13)
