9.1 ON/OFF SWITCH - FIG. 4
This machine has an on/off switch at the front of the
motor housing “I” is the ON position and “O” is the OFF
position.
9.2 FIXING TO POWER TOOLS
- FIG. 5
The adaptor is designed to attach to a stationary power
tool dust outlet i.e. contractors saw.
Alternative accessories may be purchased to fit
machines with varying sized dust outlets.
9.3 INSPECTION OF FILTERS
- FIGS. 6-7
When emptying the collection bin it is important to
inspect the paper filter for wear and tear.
Replace as necessary to increase the life of the
cartridge it surrounds.
9. BASIC OPERATION AND USE
3. WARRANTY
3.1 WARRANTY
Draper tools have been carefully tested and inspected before shipment and are guaranteed to be
free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor or
contact
Draper Tools Limited, Chandler’s Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or Product Help Line (023) 8049 4344.
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or workmanship,
repairs will be carried out free of charge. This warranty period covering labour is 12 months from
the date of purchase except where tools are hired out when the warranty period is 90 days from
the date of purchase. The warranty is extended to 24 months for parts only. This warranty does not
apply to any consumable parts, any type of battery or normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges will
be quoted and made accordingly.
This warranty applies in lieu of any other warranty expressed or implied and variations of its terms
are not authorised.
Your Draper warranty is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the warranty period.
Please note that this warranty is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
- 4 -
- 13 -
FIG.4
FIG.5
FIG.6
FIG.7
4. INTRODUCTION
4.1 SCOPE
This dust extractor is intended for non-commercial or occasional extraction from stationary
woodworking machines. It is not intended to be adapted to extract from hand held power tools in
the workplace as Health and Safety guidance recommends use of a “Class M” extractor when
using handheld tools. It is not intended to replace Personal Protective Equipment and Draper
always recommend the use of a suitable dust mask when using tools which generate dust or
airborne particles. This machine must not be used to extract metallic debris, glass or water.
4.2 SPECIFICATION
Stock no. ......................................................................................................................... 54253
Part no. ....................................................................................................................... DE1050B
Rated voltage ........................................................................................................... 230V/50Hz
Rated input ..................................................................................................................... 1100W
Air flow .......................................................................................................................... 3m
3
/min
Filtration (dia.) .............................................................................................................. 5 micron
Intake diameter .............................................................................................................. 100mm
Bag dimensions .......................................................................................... 230(D) x 360(H)mm
Weight ............................................................................................................................... 11kg
ALWAYS WEAR AN APPROVED DUST MASK AND GOGGLES.
4.3 HANDLING & STORAGE
– Care must be taken when handling this product.
● Dropping this power tool could have an effect on its accuracy and could also result in
personal injury. This product is not a toy and must be respected.
– Environmental conditions can have a detrimental effect on this product if neglected.
● Exposure to damp air can gradually corrode components.
● If the product is unprotected from dust and debris, components will become clogged.
● If not cleaned and maintained correctly or regularly, the machine will not perform at its best.
NOTE: Remove plug from the socket before carrying
out adjustment, servicing or maintenance.
Remove hose, adjustable retaining clips (x2) and
adaptor from the collection bin.
8.1 FIX HOSE TO COLLECTION TANK
- FIGS. 1 - 2
Place retaining clip over hose. Attach the same end of
the hose over dust inlet hole.
Tighten with a flat head screwdriver.
8.2 FIX MOTOR TO COLLECTION TANK -
FIG. 3
Place extractor lid/motor housing onto bin, positioning
the on/off switch to the front.
NOTE: Lid securing strap (9) must be fitted at all
times, except during maintenance.
8. PREPARING THE DUST EXTRACTOR
(4)
(11)
- 12 -
- 5 -
(9)
FIG.1
FIG.2
FIG.3
