6. Assembling the Sprayer
– 10 –
6.3 Attaching Spray Gun Hose Guide
to Tank (Fig.6 – Fig.8)
1. Route the spray gun hose
10
through the hose guide
E
.
6 Fig.
E
D
2. Then secure the hose guide to the tank using the bolt
D
.
7 Fig.
8 Fig.
6.4 Fitting Spray Gun to Hose (Fig.9)
1. Slide a hose clamp
C
over the end of the hose
10
.
2. Push the end of the hose onto the spray gun
9
connector. Then tighten the clamp to secure.
9 Fig.
6.5 Fitting Broadcast Lance Assembly
to Tank (Fig.10)
(26176 and 26180 only).
10 Fig.
C
1. Slide a hose clamp
C
over the end of the hose
8.3
attached to the broadcast lance assembly
8
.
2. Then push the end of the hose onto pump
4
connector
4a
and tighten the clamp to secure.
3. Clip the lance onto the bracket
7
on top of the tank.
