OPERATING INSTRUCTIONS
Powering the light
The Dracast PLUS Series LED500 has three power options to choose from.
- A/C Power - Plug the power supply (included) into the XLR port on the back
of your LED500. Press the power switch to “ON”
- V-Mount Battery - Attach a V-Mount lithium-ion battery (not included) to the
V-Mount battery plate included with your LED500. Press the power switch to
“BATTERY”
- Gold Mount Battery - Attach a Gold-Mount lithium-ion battery (not included)
to the Gold-Mount battery plate included with your LED500. Press the power
switch to “BATTERY”
Understanding the Controls
Your Dracast PRO Series is equipped with full DMX 512 remote functionality.
The dimming and color controls (if available) can be controlled either via a
standard DMX controller or locally by using the control knobs
on the back of the xture.
The control panel has an LCD display and four buttons directly below it. These
four buttons perform the following actions.
SETUP - Cycles through each adjustable option. (Currently selected menu item
ashes.)
UP - Adjust the selected item up.
DOWN - Adjust the selected item down.
ENTER - Conrms the current selection.
PHOTOMETRIC DATA
LED500 PLUS 5600K
DRPL-LED500-DV/DG
3 ft / 0.9 m 6 ft / 1.8 m 9 ft / 2.7 m 12 ft / 3.6 m
511 fc
5500 lux
144 fc
1550 lux
53 fc
725 lux
40 fc
430 lux
LED500 PLUS 3200K
DRPL-LED500-TV/TG
353 fc
3800 lux
107 fc
1150 lux
49 fc
530 lux
28 fc
300 lux
LED500 PLUS
3200K - 5600K
DRPL-LED500-BV/BG
251 fc @ 3200K
409 fc @ 4400K
181 fc @ 5600K
2700 lux @ 3200K
4400 lux @ 4400K
1950 lux @ 5600K
70 fc @ 3200K
116 fc @ 4400K
49 fc @ 5600K
750 lux @ 3200K
1250 lux @ 4400K
530 lux @ 5600K
33 fc @ 3200K
56 fc @ 4400K
25 fc @ 5600K
350 lux @ 3200K
600 lux @ 4400K
265 lux @ 5600K
19 fc @ 3200K
33 fc @ 4400K
14 fc @ 5600K
200 lux @ 3200K
350 lux @ 4400K
150 lux @ 5600K
