06.8.1 LED status indicators

LED LED LED status Meaning Troubleshooting

(02)

Camera

front

ﬂashes red

Camera is in setup mode.

PIR sensor is not active.

Wait until the camera automatically switches

to working mode. Alternatively, press and hold

the TEST button (13) for 5 seconds. If the ca-

mera is in working mode, the LED goes out.

(17a)

ﬂashes slowly green Camera status is being checked.

✅

lights constantly green Camera is ready for use.

✅

lights constantly red Camera is not ready for use. Check which other LED is red or ﬂashing.

ﬂashes slowly yellow Debug mode active. Please contact DÖRR Service.

(17b)

ﬂashes slowly green

Connection establishment to the mobile

network.

✅

lights constantly green

Connection to the mobile network esta-

blished.

✅

lights constantly yellow The signal strength is mediocre.

✅

ﬂashes slowly yellow The signal strength is weak.

✅

lights constantly red Connection to the mobile network failed.

Make sure that:

•

the SIM card has credit.

•

the SIM card is inserted correctly.

•

the camera supports the network provider

used (see chapter 6.4).

ﬂashes slowly yellow No SIM card inserted. Insert a SIM card.

ﬂashes red and green alternately Critical error! Please contact DÖRR Service.

(17c)

⬇

with

batteries

ﬂashes slowly green Camera connected to power supply.

✅

lights constantly green Battery capacity more than 60%.

✅

lights constantly yellow Battery capacity between 30-60%.

✅

lights constantly red Battery capacity below 30%. Insert fresh batteries as soon as possible.

ﬂashes quickly red

Battery capacity insucient for opera-

tion.

Insert fresh batteries.

(17c)

⬇

with

18650

rechar-

geable

batteries

ﬂashes slowly green

Camera connected to power supply/solar

panel. Inserted 18650 batteries will be

charged.

✅

lights constantly green Inserted 18650 batteries are fully charged.

✅

lights constantly yellow Battery capacity between 30-60%.

✅

lights constantly red Battery capacity below 30%.

Charge the 18650 Li-ion batteries in a timely

manner.

ﬂashes quickly red

Battery capacity insucient for opera-

tion.

Charge the 18650 Li-ion batteries immediately.

(17d)

lights constantly green SD card inserted and ready for operation.

✅

lights constantly yellow SD card inserted - card is full!

Delete ﬁles from the memory card and refor-

mat the card (see chapter 6.3.2)

lights constantly red

No SD card inserted or SD card locked or

formatted incorrectly.

Please refer to chapter 6.3.

ﬂashes quickly green Data is being written to SD card.

✅

ﬂashes quickly red for 5 sec., then returns

to original status

Data cannot be written to SD card. Please check the other SD card status.

ﬂashes slowly yellow Memory card is being formatted.

✅
