14
TECHNICAL SPECIFICATIONS
GENERAL
Front panel
3 mm (0.12 in)
For further materials and colors
see material board and
www.doorbird.com.
Mounting type
Flush- or surface-mounted,
mounting housing sold separately
Power supply
57 V DC (max. 15 W) or PoE+
(Power over Ethernet 802.3at)
Touch Display
Module 7
7″ LCD touch display
illuminated, name directory (max.
1000 entries)
Accessibility
module
• Approval according to DIN 18040
• Pictograms [calling, speaking,
door opening] via Display
• Door opening acoustics
• Hearing loop
Connectors
• RJ45 for LAN/PoE+
• 2x Bistable latching relay #1,
max. 24 VDC/AC, 1 A
• External input (eg. door opener
button)
• Wiegand
• 48 - 57 V DC 1A input (+, -)
• Relays can be expanded /
detached with DoorBird I/O Door
Controller
• 2x Call button port
• 1x Module port (keypad,
fingerprint)
• 1x USB Type-C Module port
(touch display)
Protection Class
IP65
Approvals
CE, FCC, IC, RoHS,
REACH, WEEE, IEC/EN 62368,
IEC/EN 62471
Dimensions
412 x 176 x 48,75 mm (H x W x D)
16.22 x 6.93 x 1.92 in (H x W x D)
Operating
conditions
-25 to +55°C / -13 to 131°F
Humidity 10 to 85 % RH
(non-condensing)
Scope of delivery
1x Main Electrical Unit
1x Touch Display Module 7
1x Front panel
1x RFID key fob
1x Screwdriver
1x Quickstart Guide with Digital
Passport
1x Installation manual
1x Small parts
Warranty
see www.doorbird.com/warranty
CURRENT SYSTEM REQUIREMENTS
System
requirements
Mobile device: Newest iOS on
iPhone/iPad, newest Android on
Smartphone/Tablet
Internet: High-Speed Landline
Broadband Internet connection,
DSL, cable or fiber optic, no socks
or proxy server
Network: Ethernet Network, with
DHCP
Recommended
installation height
Camera lens should be at a min.
height of 145 cm (57 in). Before
the installation please determine
your optimal installation height.
VIDEO
Camera
HDTV 1080p, dynamic (VGA –
HDTV)
Lens
High-end ultra wide-angle
hemispheric lens
180° (D), 150° (H), 82° (V),
straightened,
IR-capable
Night vision
YES, LIGHT SENSOR, AU-
TOMATIC IR-CUT FILTER,
INFRARED LEDS ( NM)
AUDIO
Audio
components
Speaker and microphone, noise
reduction and echo cancellation
(ANR, AEC)
Audio streaming
Two-way, full duplex
NETWORK
Ethernet
RJ45 jack, PoE+ IEEE 802.3at,
10/100 Base-T
Supported
protocols
HTTP, HTTPS, SSL/TLS, Bonjour,
DNS, RTSP, RTP, TCP, UDP, RTCP,
ICMP, DHCP, ARP, SIP, DTMF (RTP
[RFC-2833], SIP INFO [RFC-2976]),
STM
MOTION SENSOR
Type
Active
Detection angle
80° (H), 50° (V)
Range
1 - 6 m (3.3 - 19.7 ft), depends on
environment, configurable in 1 m
(3.3 ft) steps.
Technology
4D. Based on multiple integrated
sensors and algorithms, e.g. Radio
Frequency Energy (RFE)
Configuration
Via App, e.g.
Range (1 - 6 m / 3.3 - 19.7 ft)
Movement direction (coming,
leaving, both)
Individual events (e.g. switch a
relay, push notification, SIP call
[audio/video], HTTP(s) requests)
Individual schedules
