CURRENT SYSTEM REQUIREMENTS
System
requirements
Mobile device: Newest iOS on
iPhone/iPad, newest Android on
Smartphone/Tablet
Internet: High-Speed Landline
Broadband Internet connection,
DSL, cable or fiber optic, no socks
or proxy server
Network: Ethernet Network, with
DHCP
Recommended
installation height
Camera lens should be at a min.
height of 145 cm (57 in). Before
the installation please determine
your optimal installation height.
VIDEO
Camera
HDTV 720p, dynamic (VGA –
HDTV)
Lens
High-end ultra wide-angle
hemispheric lens 180° (D), 140°
(H), 100° (V), straightened, IR-
capable
Night-vision
Yes, light sensor, automatic IR-cut
filter, 12 Infrared LEDs (850 nm)
MOTION SENSOR
Type
Active
Detection angle
54° (H), 70° (V)
Range
1 - 10 m (3.3 - 32.9 ft), depends on
environment, configurable in 1 m
(3.3 ft) steps.
If a “Display Module” is connected
to the Main Electrical Unit, the
range is limited to 1 m (3.3 ft).
Technology
4D. Based on multiple integrated
sensors and algorithms, e.g. Radio
Frequency Energy (RFE)
Configuration
Via App, e.g.
• Range (1 - 10 m / 3.3 - 32.9 ft)
• Movement direction (coming,
leaving, both)
• Individual events (e.g. switch a
relay, push notification, SIP call
[audio/video], HTTP(s)
notification)
• Individual schedules
RFID
Type
Active Reader Passive Tag (ARPT)
system
Standard
ISO/IEC 18000-2:2009 Part 2,
EM4100, EM4102
Frequency
125 KHz
Range
0 - 3 cm, depends on environment
Antenna
Internal
Compatible
Transponder
RFID key fobs, sold separately,
see www.doorbird.com/buy
Up to 200 tags manageable
Configuration
Via App, e.g.
• Tag (add, delete)
• Individual events (e.g. switch a
relay, SIP call [audio/video],
HTTP(s) notification)
• Individual schedules
• RFID history available for
60 minutes in the app
Accessibility
module*
• Separate power supply:
15 - 48 VDC, 1 A
• Status display with three
pictograms [calling, speaking,
door opening], door opening
acoustics and hearing loop
• Approval according to DIN 18040
Connectors
• RJ45, for LAN/PoE
• Bistable latching relay #1, max.
24 V DC / AC, 1 A, e.g. for electric
door opener
• Bistable latching relay #2, max.
24 V DC / AC, 1 A, e.g. for electric
door opener
• External input for external door
opener button
• 15 V DC input (+, -), max. 15 W
• Relays can be expanded /
detached with DoorBird I/O Door
Controller
Protection Class
IP65, IK08
Approvals
CE, FCC, IC, UKCA, RoHS,
REACH, WEEE, IEC/EN 62368,
IEC/EN 62471
Operating
conditions
-25 to +55°C / -13 to 131°F
Humidity 10 to 85 % RH
(non-condensing)
Scope of delivery
1x Main Electrical Unit
1x Front panel*
(110 - 240 V AC to 15 V DC)
1x RFID key fob
1x Screwdriver
1x Quickstart Guide with Digital
Passport
1x Installation manual
1x Small parts
Warranty
see www.doorbird.com/warranty
AUDIO
Audio
components
Speaker and microphone, noise
reduction and echo cancellation
(ANR, AEC)
Audio streaming
Two-way, full duplex
NETWORK
Ethernet
RJ45 jack, PoE 802.3af Mode-A,
10/100 Base-T
Supported
protocols
HTTP, HTTPS, SSL/TLS, Bonjour,
DNS, RTSP, RTP, TCP, UDP, RTCP,
ICMP, DHCP, ARP, SIP, DTMF (RTP
[RFC-2833], SIP INFO [RFC-2976]),
STM
