COMPONENTS*
1x Quickstart guide
with Digital Passport
1x Drilling template 1x Power supply unit
(mains adapter)
with up to four
country-specific
adapters
Small parts
1x Installation manual
1x Flush-mounting
housing
(flush-mounted model)
1x Main Electrical Unit
with front panel
1x Wall-mounting bracket
(surface-mounted model)
1x Disassembly tool
for screw connection
terminal plug
THIS SIDE UP
* The sketches in this manual may differ from the purchased model.
1) Fingerprint reader
2) Dual frequency RFID reader (125 KHz, 13.56 MHz)
3) Bluetooth transceiver
4) Status icons with Diagnostic LEDs
5) Security screw
6) Wiegand jack
7) Screw connection terminal
8) SETUP Button (SET) of the device to e.g.
configure the WiFi interface of the device using
the DoorBird App
The flush-mounted model may differ optically.
DEVICE
Front
Back
2
4
1
5
3
1x RJ45 adapter
WIFI
6
7
8
1x A8005 RFID Key Fob
1x Screw connection
terminal plug
