ENGLISH
9
ACTIVATING THE DEVICE
Plug the enclosed power supply unit (mains adapter) into a wall socket. Switch on the power leading to the
assembly location.
You can see if the device receives power by checking the PWR-LED, which lights up after the device gets
connected to power. If the PWR LED does not light up, please check whether you have connected the positive
pole and negative pole to the device correctly.
PWR LED
You can check if the power supply and PoE supply of the device are working by checking the PWR LED. The
PWR-LED should be active.
red = Power on, no PoE device connected
blue = PoE IEEE 802.3af device connected
green = PoE+ IEEE 802.3at device connected
TECHNICAL SPECIFICATIONS
Dimensions
81 x 44,75 x 31 mm (L x W x H)
3.19 x 1.76 x 1.22 in (L x W x H)
Power supply 57 V DC, 1A
Power
consumption
Up to 35 W
Operating
conditions
0 to +55°C / 32 to 131°F
Relative Humidity 0 % to 85 %
(non condensing)
Protection class IP 30
Mounting
• Top-hat rail / DIN rail
• Wall mounting
Approvals CE, FCC, IC, RoHS, WEEE, UKCA
Scope of delivery
1x PoE Injector
1x Power supply unit (mains
adaptor) with up to 4 country-
specific outlet adaptors
(100 - 240 V AC to 57 V DC)
1x Installation Guide
1x Small parts
Connectors &
Interface
• LAN in 10/100/1000 Mbit/s RJ45
• LAN/PoE out 10/100/1000
Mbit/s RJ45
• 57 V DC Input (-/+)
LED PWR LED
PoE Out
PoE IEEE 802.3at (Mode A+B,
Midspan)
Network speed 10/100/1000 Mbit/s
Cable length
max. 80 m/262 ft (Input +
Output) via Cat.5e/Cat.6/Cat.7
Weight
70 g
EAN 4260423913868
